PET Metal Pot Film Membrane 2.0mm Industrial Numeric Keypad
Application range of membrane switch keyboard: all metal panels, self-service equipment, hospital equipment, self-service car washing machines, express cabinets, various shopping malls, banks, remote controls, household appliances, etc.;The membrane switch keyboard has the advantages of resistance to friction, water, dust, harmful gas, long service life, stable performance, etc., making it more and more widely used in various fields;
Description of the waterproof plastic keyboard: The product is easy to use, just pull the back glue directly and stick it on the required product panel. The product buttons can be customized in different languages, different colors, and different interfaces according to customer needs; the matrix interface spacing is 2.54, The button part has a 0.1mm bump, which makes the product more hand-feel to operate, beautiful appearance, with LED light hole;
The function of the keyboard buttons: the button material is PC, PET, the adhesive material is 3M467/468 material, which is very sticky and not easy to fall off; the connector is a 2.54mm female connector, the length can be customized, and the buttons can be flat or embossed ；
Parameters of the digital PET keyboard switch:
Product size | 123*57mm |
Line length | 28*100mm (customizable) |
Material | PET / PC / PMMA / Aluminum |
Printing area | ≤800mm |
Thickness | 0.023mm-2.0mm |
Quantity | ≥50pcs |
Printing | silk screen, four-color printing |
Substrate pressure | 2kDVC |
Reliability and service life | > one million times |
Working current | ≤100mA |
Insulating ink withstand voltage | 100VDC |
Insulation resistance | ≥100MΩ |
Rebound time | 6ms |
Front picture of 21-key keyboard:
Picture of the connection line of membrane switch keyboard:
Product Tags:
|
|
2.54 Pitch Industrial Numeric Keypad 2.0mm Membrane Switch Keyboard Images
|
